Edge AI PCs | Edge Computing Industrial PC

Edge for AI PCs - Micro Platform for Edge Computing PC

Edge Computing is a distributed computing model in which it occurs near a physical location where data is collected and analyzed, rather than on a centralized server or in the cloud. This new infrastructure includes sensors to collect data and Edge servers to securely process data in real time in the field, as well as connect other devices such as laptops and smartphones to the network.

Micro Platform for Edge computing is important as it creates new and improved ways for industrial and enterprise-grade enterprises to maximize operational efficiency, improve productivity and security, automate all major business processes, and ensure continuous availability. It is the leading method for achieving the digital transformation of your business.

The concept of Micro Platform for Edge Computing is integral to the next industrial revolution, transforming manufacturing and services.

________________________________________________________________________________________________________________

More Edge AI PC @ Desktop Version

Model	Processor	Chipset	Memory	Graphics	Network	M.2	MSata	USB2.0	USB3.0	Ports	Expansion	OtherIO	Audio
2600L2	N2600	NM10	1 DDR3SO	Intel HD 3600	2 Realtek		option	4 R+2 H		1 VGA	2 MiniPCIe+PCI	2xPS/2	5.1 ALC662
Nano-J1900L2	J1900	Bay Trail	1 DDR3SO	7th Gen. HD	2 Realtek		1	2 R+2 H	2 F	1 HDMI+1 VGA	MiniPCIe-F		5.1 ALC662
H8100L2/H8100L3	Socket 1150 Haswell	H81	2 DDR3	Intel HD 5000	2 Realtek	2-8	1	4 R+1 H	2 R	1 HDMI+1 DVI+1 VGA	1 MiniPCIe+PCIe 16x	1xPS/2	5.1 ALC662
1750C-6DP	Socket 1150 Haswell	H81	2 DDR3	Radeon 7750/7870 Nvidia NV810	2 Realtek		1	4 R+1 H	2 R	6 or 8 DP	MiniPCIe+PCIe 16x		5.1 ALC662
2550L2D	D2550	NM10	2 DDR3SO	Intel HD 3650	2 Broadcom		2	4 R+2 H	2 R	1 HDMI+1 VGA	PCIe 1x	2xPS/2	5.1 ALC662
H110AEL2/i1000A12	6/7th Socket 1151	H110	2 DDR4SO	Intel HD 530 Intel HD 630	1 Intel\i219V+1 Intel\i211AT	2-8	1	4 H	4 R	1 DP+1 HDMI+1 VGAH	MiniPCIe+PCIe 4x	GPIO	7.1 ALC887
J1900L4	J1900	Bay Trail	1 DDR3SO	7th Gen. HD	4 Intel		1	2 R+2 H		1 VGAH	1 MiniPCIe	GPIO	5.1 ALC662
J1900L6	J1900	Bay Trail	1 DDR3SO	7th Gen. HD	6 Intel		1	2 R		1 VGAH	MiniPCIe+PCIe 8x		5.1 ALC662
1U-12DP	Socket 1155 Ivy Bridge	Z77	2 DDR3	2 Radeon 7750	2 Intel		1	2 R+4 H	2 R	12 DP+1 VGA	MiniPCIe		option
2550L2D-MxPC	D2550	NM10	2 DDR3SO	Intel HD 3650	2 Broadcom		2	4 R+2 H	2 R	1 HDMI+1 VGA	PCIe 1x	2xPS/2	5.1 ALC662
i5-6200FL2	i5-6200u	Skylake-u	2 DDR3SO	Intel HD 520	2 Realtek	2-8	1	2 H	2 R+2 H	1 HDMI+1 DVI	2 MiniPCIe		5.1 ALC662
Q170A2-3HDMI	6/7th Socket 1151 vPro	Q170	2 DDR4SO	Intel HD 530 Intel HD 630	2 Intel	2-8	1	4 H	4 R	2 HDMI+1 HDMI2.0+1 LVDS	2 MiniPCIe+PCIe 4x	GPIO+TPM	7.1 ALC887
Nano-J1900L4	J1900	Bay Trail	1 DDR3SO	7th Gen. HD	4 Intel\WG82573V		1	2 F+2 H	1 F	1 VGA	MiniPCIe-F	GPIO	5.1 ALC662
H110-G330-6DP	6/7th Socket 1151	H110	2 DDR3SO	Radeon 7750	2 Intel		1	4 R	1 F	6 DP	2 MiniPCIe		5.1 ALC662
Nano-N3450L2/J3455L2	N3350	Apollo Lake	1 DDR3SO	Intel HD 500	2 Realtek		1	2 F	4 F	2 HDMI+1 VGA	MiniPCIe		5.1 ALC662
i42F/i43F	N3350	Apollo Lake	1 DDR3SO	Intel HD 500	2 Realtek		1	2 R	3 R	1 HDMI+1 DP	2 MiniPCIe		5.1 ALC662
3855Z/6100Z	3855u	Skylake-u Kaby Lake-u	2 DDR4SO	Intel HD 520	1 Realtek+1 Intel	2-8		2 R	2 F	1 DP+1 HDMI	MiniPCIe		5.1 ALC662
H8700L8-1U	Socket 1150 Haswell	H87	2 DDR3SO	Intel HD 5000	8 Intel/F	2-8	1	2 F+4 H	2 H	1 VGA	MiniPCIe+PCIe 8x
G302F/G303	i5-4200u	Haswell-u	2 DDR3SO	Nvidia GT730/GT630	1 Realtek		1	2 R+1 H		1 DP+2 HDMI	MiniPCIe		5.1 ALC662
H110L2C12	6/7th Socket 1151	H110	2 DDR4	Intel HD 530 Intel HD 630	2 Realtek	2-8	1	2 R+2 H	4 R	1 DP+1 HDMI+1 VGA	2 MiniPCIe+PCIe 16x	1xPS/2	5.1 ALC662
i5-6200L2B	i5-6200u	Skylake-u	2 DDR3SO	Intel HD 520	2 Realtek	2-8	1	2 H	2 R+2 H	2 HDMI	2 MiniPCIe		5.1 ALC662
H110L2A/i1000A13	6/7th Socket 1151	H110	2 DDR4	Intel HD 530 Intel HD 630	2 Realtek	2-8	1	6 H	2 R	1 HDMI+1 VGA	MiniPCIe+PCIe 4x	GPIO	5.1 ALC662
J1900AEL2	J1900	Bay Trail	1 DDR3SO	7th Gen. HD	2 Realtek\RTL8111F		1	2 R+2 H	1 R	2 HDMI+1 VGAH+1 LVDS/H	MiniPCIe-F+PCIe 1x	GPIO	5.1 ALC662 7.1 ALC892
N4200AEL2	N4200	Apollo Lake	2 DDR3SO	Intel HD 505	2 Intel\i211AT		1	5 R	4 R	1 HDMI+2 DP+1 LVDS	MiniPCIe+PCIe 1x	GPIO+TPM	5.1 ALC662
i39F-J1900	J1900	Bay Trail	1 DDR3SO	7th Gen. HD	2 Realtek		1	2 R	3 R	1 HDMI+1 VGA	MiniPCIe		5.1 ALC662
i59F	i5-6200u	Skylake-u	2 DDR4SO	Intel HD 510	1 Intel\i219LM+1 Realtek\RTL8111F	2-8	1	2 R	2 R+2 S	2 DP+1 VGA	2 MiniPCIe	TPM	5.1 ALC662
i61F	i5-7200u	Kaby Lake-u	2 DDR4SO	Intel HD 620	1 Intel\i219LM+1 Realtek\RTL8111F	2-8	1	2 R	2 R+2 S	2 DP+1 VGA	2 MiniPCIe	TPM	5.1 ALC662
Q170A	6/7th Socket 1151 vPro	Q170	2 DDR4SO	Intel HD 530 Intel HD 630	2 Intel	2-8	1	4 H	4 R	1 DP+1 HDMI+1 VGAH+1 LVDS	2 MiniPCIe+PCIe 4x	GPIO+TPM	7.1 ALC887
H110L2V	6/7th Socket 1151	H110	2 DDR4	Intel HD 530 Intel HD 630	2 Realtek\RTL8111H	2-8	1	2 R+4 H	4 R	2 DP+1 VGA+1 HDMI/H	MiniPCIe+PCIe 16x		5.1 ALC662
N3350AEL2	N3350	Apollo Lake	2 DDR3SO	Intel HD 500	2 Realtek	1	2	4 H	4 R	1 HDMI+1 VGA+1 LVDS	MiniPCIe+PCIe 1x	LPT+GPIO	7.1 ALC887
Slim-7000L4	i7-7660u	Kaby Lake-u	1 DDR4SO	Intel HD 610	4 Intel	2-8	1	2 R+2 H	2 R+2 H	1 HDMI	MiniPCIe+PCIe 1x	1xPS/2+TPM	5.1 HDMI
Nano-J1900L2V3	J1900	Bay Trail	1 DDR3SO	7th Gen. HD	2 Realtek		1	2 F+2 H	2 F	1 HDMI+1 VGA	MiniPCIe-F		5.1 ALC662
H310L4	8/9th Socket 1151	H310 Q370	2 DDR4SO	Intel UHD 630	4 Intel\i211	2-8	1	4 H	2 R+2 F	1 VGA	MiniPCIe+PCIe 4x	GPIO	5.1 ALC662
J1900SFP	J1900	Bay Trail	1 DDR3SO	1 DDR3L SO-DIMM	7 intel/F\i211-AT+2 SFP/F		1	3 F			MiniPCIe(Opt)+PCIe 8x	GPIO	5.1 ALC662
Nano-N2807L2	N2807	Bay Trail-u	1 DDR3SO	7th Gen. HD	2 Intel/I211		1	1 R+4 H	1 R	1 HDMI+1 VGA+1 LVDS	2 MiniPCIe	LPT+1xPS/2/H	5.1 ALC662
Nano-J1900L2C2	J1900	Bay Trail	1 DDR3SO	7th Gen. HD	2 Realtek		1	3 F+2 H	1 F	1 HDMI+1 VGA	2 MiniPCIe		5.1 ALC662
Slim-7000AEL2	i5-7200u	Kaby Lake-u	1 DDR4SO	Integrated	2 Realtek\RTL8111F	1-4	2	4 H	4 R	1 DP+1 HDMI+1 eDP/H\LVDS	PCIe 4x	GPIO+LPT	5.1 ALC662
Nano-E310	N3350	Apollo Lake	1 DDR3SO	Intel HD 505 Intel HD 500	1 Realtek	1-4	1			1 HDMI+1 DP			5.1 ALC662
H410A1	10th Socket 1200	H410	2 DDR4SO	Intel UHD 630	1 Reltek\RTL8111F	1	2	4R	2R+2F	1 DP + HDMI		LPT/S	5.1 ALC662
B365AL2	6/7/8/9th Socket 1151	B365	2 DDR4SO	Integrated	2 Realtek\RTL8111H	1-4/6/8	2	4 H	4 R+2 H	1 DP+1 HDMI+1 LVDS/H		TPM	2.1 ALC269
Nano-A320L2	Socket AM4 Ryzen 3rd G-Series	AMD A320	2 DDR4SO	Radeon Vega	2 Realtek\RTL8111H	1-4/6/8	1	2 R+1 H	1 F+2 R	1 HDMI+1 DP+1 VGA		TPM+SD/F	2.1 ALC269
Q370L3E2	8/9th Socket 1151 vPro	Q370	2 DDR4SO	Intel UHD 630	1 Intel\i219V+2 Intel\i210AT	1-4/8	4	2 R+4 H	4 R+1 H	2 DP+1 DVI+1 LVDS/H	1 PCIe 16x+1 PCIe 4x	GPIO+LPT	7.1 ALC888
H310CAL2	6/7/8/9th Socket 1151	H310C	2 DDR4SO	Intel UHD	2 Realtek\RTL8111H	1		2 R	2 R+2 F	1 DP+1 HDMI		LPT/S	5.1 ALC662
Q370-15HDMI	8/9th Socket 1151 vPro	Q370	2 DDR4SO	2 Radeon 8860	2 Intel\I211AT	1-8/4	1	2 R	1 F+2 R	15 HDMI2.0			5.1 ALC662
H170L8-1U	6/7th Socket 1151	H170	2 DDR4SO	Intel HD 530 Intel HD 630	8 Intel/F\WGI211AT	2-8	1	option 2 R+4 H	2 F+2 H	1 HDMI/H+1 HDMI(Option)	PCIe 8x	1F-Console(RJ45)	1F-Console(RJ45)
Nano-U10L2	i7-10710U	Comet Lake-u	2 DDR4SO	Intel UHD 4K	2 x Intel® i211+i219	1		2F + 2S	2F + 2S	1 HDMI+ 1 DP+ 1 Type-C+ 3 USB+ 1 COM+ 2 LAN+ 1 SIM+ 1 SD+ S/PDIF		GPIO	5.1 ALC662
Nano-N6400D	N6211	Elkhart Lake	0 DDR4OB	10th Gen. UHD	1 Realtek\RTL8111H		1	2 R	2 F	1 DP+1 HDMI	MiniPCIe	1F	CM119B
TRX40-E4T	AMD Socket sTRX4	AMD TRX40	8 DDR4	8 DDR4 DIMM	1 Aquantia	2-6/8+1-3/4/6/8/10	8 R	2 F	6 R+4 F	by Graphics Card	4 PCIe 16x	1xPS/2+TPM	7.1 ALC1220
B8500L6+2SFP	Socket 1150 Haswell	B85	2 DDR3SO	Intel HD 5000	6 intel/F\82574L+2 SFP/F	2-8	1	2 H	2 F	1 VGAH	1 MiniPCIe+PCIe 1x	1 F-Console(RJ45)	USB Audio
Nano-U8L2	i5-8259u	Coffee Lake-u Comet Lake-u	2 DDR4SO	Intel UHD 4K	2 x Intel® i211+i219	1		2F + 2S	2F + 2S	1 HDMI+ 1 DP		GPIO	5.1 ALC662
Nano-U10FL2C/Nano-U10L2C	BGA-1528	Comet Lake-u	2 DDR4SO	Intel UHD 4K	2 x Intel® i211+i219	1		2F + 2S	2F + 2S	1 HDMI+ 1 DP+ 1 Type-C+ 3 USB+ 1 COM+ 2 LAN+ 1 SIM+ 1 SD+ S/PDIF			5.1 ALC662
H410AL2	10th Socket 1200	H410	2 DDR4SO	Intel UHD 630	2 Realtek\RT8111H	1		2R	2R+2F	1 HDMI+1DP/VGA		Option: LPT/S	5.1 ALC662
Nano-U11B	i7-1185G7	Tiger Lake-u	2 DDR4SO	Intel UHD	LAN + WiFi/BT + 5G/4G-LTE	1 M.2 2280		2F	4(3.1)R	2HDMI + DP+Thunderbolt4			CJC6811A
Nano-H510A/Q570A	11th/10th Socket 1200	H510/Q570	2 DDR4	Intel UHD 750	1 Intel\I219LM	2-8		3F	1F	1 HDMI2.0/F+1 DP/F	M.2-2280+M.2-2230	TPM	5.1 ALC662
Slim-H510B/Q570B	i9-11900T	Intel H510	2 DDR4SO	Intel UHD 750	2 Intel I219LM + 1 M.2 2230 + WiFi/BT		1	2 R + 3 F	2 R + 1 F	2 HDMI + 1 DC + 2 Lan			ALC662
H510MXM	11th/10th Socket-S	H510	2 DDR4SO	MXM + UHD 750/630	2 LAN + WiFi/BT	1 M.2 2280		4 F	2 R	HDMI 2.0 + DP 1.2			ALC662 (5.1)
Nano-N6000DL2	N4500	Jasper Lake	Onboard 4GB/8GB DDR4	11th Gen. UHD	2 Gigabit LAN		1	2 R	2F	1 DP + 1 HDMI	MiniPCIe		CM119B
SwapPC-U8A	i5-8259u	Whiskey Lake-u/Coffee Lake-u	2 DDR4SO	Intel Iris Plus/UHD	2 LAN + SIM	1 M.2 2280		2 R	4 F + 2 R	3 HDMI		TPM	5.1 ALC662
SwapPC-U10S	i7-10710u	Comet Lake-u	2 DDR4SO	Intel UHD 620	2 LAN + SIM	1 M.2 2280		1 F + 2 R	3 F + 2 R	2 HDMI + 1 DP		TPM	5.1 ALC662
SwapPC-U8S	i5-8259u	Whiskey Lake-u/Coffee Lake-u	2 DDR4SO	Intel Iris Plus/UHD	2 LAN + SIM	1 M.2 2280		1 F + 2 R	3 F + 2 R	2 HDMI + 1 DP		TPM	5.1 ALC662
SwapPC-U10A	i7-10710u	Comet Lake-u	2 DDR4SO	Intel UHD 620	2 LAN + SIM	1 M.2 2280		2 R	4 F + 2 R	3 HDMI		TPM	5.1 ALC662
SwapPC-J5005	Pentium J5005	Gemini Lake	2 DDR4SO	Intel UHD 605/600	2 LAN			1 F + 2 R	3 F + 2 R	2 HDMI + 1 DP		TPM	5.1 ALC662
i2312	i7-9750H	QM370/HM370	2 DDR4SO	GTX1650	LAN + WiFi/BT	2 M.2 2280		2 F + 2 H	4 R + 1 H	HDMI2.0+HDMI1.4+Type-C+eDP+HDMI2.0 H			ALC662 (5.1)
SwapPC-H510A	10/11th Socket 1200	H510	2 DDR4SO	Intel UHD 750	2 LAN	1 M.2 2280		3 F + 2 R	1 F + 2 R	3 HDMI + 1 DP		TPM	5.1 ALC662
i2313	i9-10885H	Comet Lake-u	2 DDR4SO	RTX 2060 + UHD Graphics	LAN + WiFi/BT	1 M.2 2280		2 R	4 R	HDMI 2.0 + HDMI 1.4 + DP 1.2			ALC662 (5.1)
SwapPC-X39	ARM Cortex-A53	Rockchip 3399 (SOC)	2/4GB LPDDR4	Mali T764	2/3 LAN + WiFi/BT			3 F + 2 R	1 F + 2R	3HDMI+HDMI-In		SIM, TF	ALC662 (5.1)
Z690L2V4	Intel Socket-S LGA1700	Z690 Chipset	2 DDR5	UHD 770/730/710	2 LAN + WiFi 6E	2 M.2 2280		2 H	6 R + 2 H	2 HDMI 2.0 + 2 DP	PCIe 5.0 x16		ALC897 (7.1)
H410L2	10th Gen. Socket-S	H410	2 DDR4SO	Intel® Gen9.5 Intel® Graphics DX 12*, OGL4.5	2 LAN + Wifi6 AX201 802.11	2		4H	4R	HDMI + DP + VGA	PCIe 3.0 x16		5.1 ALC662
H610V3	Alder Lake	H610	2 DDR4SO	UHD 770/730	Realtek® RTL8125B			3 R	2 R	2 HDMI, DP			Realtek® ALC897
H610A	Alder Lake	H610	2 DDR4SO	Intel® 12th Gen Xe Graphics UHD 770/730/710	1 LAN + WiFi/BT	1			4 R	1 HDMI + 1 VGA	1		7.1 ALC897
H610L2	Alder Lake	H610	2 DDR4 U-DIMM	UHD 770/730	2 LAN	M.2-2280/2242		3 R	2 R	2 HDMI, DP			ALC897
i2312B	i7-9750H	Coffee Lake	2 DDR4SO	Intel UHD 630 Graphics + Nvidia GTX-1650 4G	1 Lan + WiFi/BT + 5G-LTE	1		2 R	4 R	1 HDMI+1 DP+1 Type-C
Nano-N6400G
Nano-N6400L2C4	10th Gen Celeron/Pentium	Elkhart Platform (SOC)	DDR4 SODIMM	10th Gen UHD	2 2.5GbE LAN + 5G/4G	SSD		1 R	3 R	HDMI 2.0 + DP 1.2		4 COM	HD
H610AL2	12th Gen Socket-S series	H610	2 DDR4 SODIMM	UHD	2 LAN+WiFi/BT+5G/4G	NVMe/SSD/2.5"SATA SSD/HD		2 R	2 F	2 HDMI, DP		2 COM	7.1 ALC897
Nano-N6400C	Intel® 10th Gen Celeron/Pentium	Intel® Elkhart Lake Platform (SOC)	2 LPDDR4	UHD	1 LAN + WiFi/BT	SATA/NVMe		5 R	2 F 1 R	HDMI + DP		1 COM	7.1 ALC897
Nano-U10L2C-i3
J4000L4
i2314
i63F/i63u	i7-8665u	Whiskey Lake-u	2 DDR4SO	Intel UHD 620	1 Intel i219LM/S+1 Realtek RTL8111F/R	1	1	2 R+4 S	2 R+4 S	1 HDMI+1 HDMI2.0+1 DP	MiniPCIe	TPM	5.1 ALC662
Slim-3865L4	3865u	Kaby Lake-u	1 DDR4SO	Intel HD 610	4 Intel	2-8	1	2 R+2 H	2 R+2 H	1 HDMI	MiniPCIe+PCIe 1x	1xPS/2+TPM	5.1 HDMI
Nano-7200L2/6100L2	i3-6100u	Skylake-u Kaby Lake-u	1 DDR4SO	Intel HD 520	2 Realtek	1	1	2 R+1 H	4 F	1 HDMI+1 DP	MiniPCIe		5.1 ALC662
Nano-J6412L2C2V3	J6412	Elkhart Lake	DDR4	10th Gen UHD	LAN+WiFi	2	1	2	2	DP + HDMI
Nano-J6412U8V3
Nano-N6400L2C2
i41F	N3150	Braswell-u	2 DDR3SO	8th Gen. HD	2 Realtek		1	2 R	3 R	1 DP+1 HDMI	2 MiniPCIe	TPM	5.1 ALC662
J1900AL2	J1900	Bay Trail	1 DDR3SO	7th Gen. HD	2 Realtek		1	1 R+1 F+2 H	1 R	1 HDMI+1 VGA+1 LVDS/H	MiniPCIe-F	TPM+GPIO+1xPS/2/H	5.1 ALC662
i63C / i65C	10th/8th Gen. u-Series	Comet Lake-u/Whiskey Lake-u SOC	2 DDR4SO	10th/8th Gen. UHD Graphics	Intel® i219+Realtek® RTL8111H w/ SIM	1			4 R+2F	1 HDMI 2.0+1 HDMI 1.4+1 DP 1.2	MiniPCIe		5.1 ALC662
i12P	12th Gen Core-P Series	Alder Lake-P (SOC)	2 DDR4 SODIMM	Iris Plus	2 LAN+WiFi/BT+5G/4G	NVMe/SSD				2 HDMI 2.0 + DP 1.4		2 COM	7.1 ALC897
H310AEL2	8/9th Socket 1151	H310 Q370	2 DDR4SO	Intel UHD 630	2 Intel\i211	2-8	1	4 R+2 H	2 R+2 F	1HDMI+1DP+1VGA/H+1LVDS/H	PCIe 4x	TPM	5.1 ALC662
SwapPC-U11A	i7-1185G7	Tiger Lake-u	2 DDR4SO	Intel Iris Xe/UHD	2 LAN + SIM	1 M.2 2280		2 R	4 F + 2 R	3 HDMI		TPM	5.1 ALC662
Q470L2G	11th/10th Socket 1200	Q470	2 DDR4SO	Intel UHD	1 Intel\i219V+1 Intel\i211	2-8	2	4 H	4 R+2 F	1 DP+1 HDMI+1 HDMI2.0+1 eDP\LVDS/H+VGA header (co-lay with eDP)	1 MiniPCIe+1 PCIe 16x	GPIO+TPM	5.1 ALC662
POE-7000	i5-7300u	Integrated	2 DDR4SO	Intel HD 620	2 Intel\i211+1 Intel\i219	1-8/4	1	2 R+2 H	4 R	1 DP		4 PoE	4 PoE

Nano-N6000L2

Nano-N5095L

Nano-N6000Z

Nano-N6000L

Nano-N7000L2

Nano-N7000V3c

Nano-U8FL2C6

H110L4C6

Nano-U12B

Edge for AI PCs - Micro Platform for Edge Computing PC
