High End Gaming PC

High end gaming PC is the powerful computers with high-performance processors and large amounts of memory, designed to solve complex and voluminous computing tasks. These also include personal computers with powerful graphics accelerators.

The design features of High end gaming PC include the use of the most productive processors. AMD Ryzen Threadripper, Inte® Core X-series, and Intel Xeon are commonly used. Multiprocessor configurations are sometimes used. Typically, High end gaming PCs are equipped with a large amount of RAM. Often, graphics workstations use powerful video cards, including those on the NVIDIA RTX and NVIDIA Quadro platforms. For high performance computing, NVIDIA GPUs based on the NVIDIA Ampere architecture are used. The disk subsystem is usually represented by the fastest SSD NVMe drives. Various RAID configurations are used to speed it up.

_______________________________________________________________________________________________________________________________________________

Model	Processor	Chipset	Memory	Graphics	Network	M.2	MSata	USB2.0	USB3.0	Ports	Expansion	OtherIO	Audio
H310A1	8/9th Socket 1151	H310	1 DDR4SO	Intel UHD 630	1 Intel\i219V	1	2	4 H	4 R+2 H	1 HDMI+1 VGA/H+1 LVDS/H			5.1 ALC662
i2311	6/7/8/9th Socket 1151	H310C	1 DDR4SO	Nvidia GT1030	1 Realtek\RTL8111H		1	2 H	4 R	1 HDMI+1 LVDS/H			5.1 ALC662
H310AEL2	8/9th Socket 1151	H310 Q370	2 DDR4SO	Intel UHD 630	2 Intel\i211	2-8	1	4 R+2 H	2 R+2 F	1HDMI+1DP+1VGA/H+1LVDS/H	PCIe 4x	TPM	5.1 ALC662
Q370L3E2	8/9th Socket 1151 vPro	Q370	2 DDR4SO	Intel UHD 630	1 Intel\i219V+2 Intel\i210AT	1-4/8	4	2 R+4 H	4 R+1 H	2 DP+1 DVI+1 LVDS/H	1 PCIe 16x+1 PCIe 4x	GPIO+LPT	7.1 ALC888
Q470L2G	11th/10th Socket 1200	Q470	2 DDR4SO	Intel UHD	1 Intel\i219V+1 Intel\i211	2-8	2	4 H	4 R+2 F	1 DP+1 HDMI+1 HDMI2.0+1 eDP\LVDS/H+VGA header (co-lay with eDP)	1 MiniPCIe+1 PCIe 16x	GPIO+TPM	5.1 ALC662
Nano-H510A/Q570A	11th/10th Socket 1200	H510/Q570	2 DDR4	Intel UHD 750	1 Intel\I219LM	2-8		3F	1F	1 HDMI2.0/F+1 DP/F	M.2-2280+M.2-2230	TPM	5.1 ALC662
Nano-U10A	i7-10710u	Comet Lake-u/Whiskey Lake-u Platform (SOC)	2 DDR4SO	UHD 620 / Iris Graphics	1 Intel® i219LM+SIM	1		1	4	1 HDMI + Optional HDMI		TPM	5.1 ALC662
Nano-U10C	i7-10510u	Comet Lake-u	2 DDR4SO	Intel UHD 620	1 Realtek\RTL8111H	1-8			2 F +2 R	HDMI+DP+Type-C			2.1 ALC269
H670L2	Socket-S 12th Gen	H670 Chipset	2 DDR4, up to 64GB	UHD 770/730/710	2.5GbE LAN + 1GbE LAN, WiFi 6E	2 M.2 2280 NVMe		4 R + 1 H	2 R + 1 H	HDMI 2.1 + DP 1.4	PCIe 5.0 x16		ALC897 (7.1)
H610V3	Alder Lake	H610	2 DDR4SO	UHD 770/730	Realtek® RTL8125B			3 R	2 R	2 HDMI, DP			Realtek® ALC897
H610A	Alder Lake	H610	2 DDR4SO	Intel® 12th Gen Xe Graphics UHD 770/730/710	1 LAN + WiFi/BT	1			4 R	1 HDMI + 1 VGA	1		7.1 ALC897
H610L2	Alder Lake	H610	2 DDR4 U-DIMM	UHD 770/730	2 LAN	M.2-2280/2242		3 R	2 R	2 HDMI, DP			ALC897
i2312B	i7-9750H	Coffee Lake	2 DDR4SO	Intel UHD 630 Graphics + Nvidia GTX-1650 4G	1 Lan + WiFi/BT + 5G-LTE	1		2 R	4 R	1 HDMI+1 DP+1 Type-C
Nuc-U10c	i7-10510u	Comet Lake-u (SOC)	2 DDR4 SO-DIMM	Intel® UHD	Intel® i225				1F+2R	HDMI+MiniDP+Type-C	M.2 2230 + SATA HDD
NUC-U11L2	11th Gen. Tiger Lake	Intel® Tiger Lake (SOC)	2 DDR4	Intel® UHD Graphics	2 Intel® Gigabit					1 Mini-DP+1 HDMI	PCIe, M.2
H510L2	10th/11th Gen Socket-S	Intel H510			2 Gigabit/2.5G LAN			4	4	6xRS232/485	M.2 Wifi/BT
Z690L2V4	Intel Socket-S LGA1700	Z690 Chipset	2 DDR5	UHD 770/730/710	2 LAN + WiFi 6E	2 M.2 2280		2 H	6 R + 2 H	2 HDMI 2.0 + 2 DP	PCIe 5.0 x16		ALC897 (7.1)
V1807B-4HDMI	V1807B	AMD V1000	2 DDR4SO	Radeon Vega	1 Realtek\RTL8111H	1-8/4	1	1 R	2 F+1 R	4 HDMI2.0	MiniPCIe
Slim-U12V4
NUC-Ryzen-u7	Ryzen 7 7730u	AMD 7th Gen. u-Series Ryzen™ 7 (SOC)	2 DDR4 SODIMM	Radeon Graphics						2 HDMI 2.0 + Type-C	2 M.2/PCIe 4x NVMe
Nano-U10F	i7-10510u	Comet Lake-u	2 DDR4SO	Intel UHD 620	1 Realtek\RTL8111H	1-8	1	2 F	2 F + 2 R	1 HDMI+1 DP			2.1 ALC269
Nano-U8MX250	i7-10510u	Comet Lake-u/Whiskey Lake-u Platform (SOC)	2 DDR4SO	Intel UHD, Nvidia MX250	1 Realtek® RTL8111	1		2 F	2 R		M.2-2280+M.2-2230		Intel® HD
