E7002A8T

Single AMD EPYC™ 7002-Series, 2 M.2 + 2 SlimSAS x8 (each: 8 SATA3 or 2 NVMe), Dual 10GBase-T LAN, 8 DDR4 up to 2TB 8-Channel memory, 5 PCI-E 4.0 x16 + 2 PCI-E 4.0 x8
Featured Highlights
Single AMD EPYC™ 7002 Series Processor
2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs
5 PCI-E 4.0 x16 + 2 PCI-E 4.0 x8
2 M.2, 2 SlimSAS x8 (each: 8 SATA3 or 2 NVMe)
Dual 10GBase-T LAN via Broadcom BCM57416
ASPEED AST2500 BMC graphics
Up to 6 USB 3.0 ports(4 rear + 2 via header)
7 PWM 4-pin Fans with tachometer status monitoring
SKU: E7002A8T
Product specifications
Attribute nameAttribute value
Processor
• Single AMD EPYC™ 7002 series Processor
• Socket SP3
Chipset
• System on Chip
Memory
• 8 DIMM slots
• Supports up to 2TB Registered ECC DDR4 3200MHz SDRAM
• 8-channel memory bus
• DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs
On-Board Devices
• SATA3 (6 Gbps)
• Support for Intelligent Platform Management Interface v.2.0
• IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
• ASPEED AST2500 BMC
• Dual 10GBase-T LAN via Broadcom BCM57416
• 1 Realtek RTL8211F PHY (dedicated IPMI)
• ASPEED AST2500 BMC
Expansion Slot
• 5 PCI-E 4.0 x16
• 2 PCI-E 4.0 x8
I/O Ports
• 2 SlimSAS x8 (each: 8 SATA3 or 2 NVMe)
• Dual 10GBase-T LAN ports
• 1 RJ45 Dedicated IPMI LAN port
• 6 USB 3.0 ports (4 rear + 2 via header)
• 1 VGA port
• 1 COM port (rear)
• 1 TPM 2.0 header
Chassis
• 2U chassis supports for maximum motherboard sizes - 13.68" x 13", E-ATX 12" x 13", ATX 12" x 10" motherboards
• 8 x 3.5" hot-swap SAS3/SATA drive bay, 2 x 3.5" fixed drive bay
• 8-port 2U SAS3 12Gbps TQ backplane, support up to 8x 3.5-inch SAS3/SATA3 HDD/SSD
• 1U 600W platinum efficiency multiple output power supply w/PMBus
• 7 low-profile expansion slot(s)
• 3 x 8cm (7000 RPM) hot-swap PWM cooling fan(s)
BIOS
• AMI 256Mb SPI Flash EEPROM
• Plug and Play (PnP)
• DMI 2.3
• PCI 2.2
• ACPI 5.1
• USB Keyboard Support
Application
• Cloud Computing, Cloud Server, High Performance Storage, Database Server
Environment
• Operating Temperature: 0 to +55 C
• Non operating temperature: -20 to +70 C
• Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz
• Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz
• Shock - Operating: 3,920 m/s2 (400G) 2ms
• Shock - Non-Operating: 8,820 m/s2 (900G) 1ms
• Operating Relative Humidity: 8% to 90% (non-condensing)
• Non-operating Relative Humidity: 5% to 95% (non-condensing)
• MTBF: 50,000 Hours
• RoHS Compliance
*
*
*
